Create a static cursor from an image
This article provides information on the following topics:
Tryout or Professional Edition
We recommend to learn more aboutcursors before following this tutorial
Opening the image file
browse your folders and select your file (Windows® standard dialog box).
A built-in Axialis File Browser window opens. Browse your disks, see
the thumbnail preview and double-click the image file you wish to open.
In the Recently
Used zone (in the main toolbar), type the full
pathname of the image file you wish to open then hit Enter.
file opens in a document window.
much more convenient to create cursors. The following image formats can
Creating a static cursor from this image
3. If your image is opaque, you can create transparent areas. Using the following tutorial, you can easily transform the white background to transparency: Add Transparency to an Opaque Image.
4. If necessary, select the
portion of image: Use the selection tool (upper-left button of the tool palette) and select the portion of image
you whish to use (do not cut the shadow if there is one around the object).
When done, an animated dashed rectangle has been created.
5. When the
selection is done, choose Image/Create
6. The dialog
box New Cursor From Image opens
(see below). In the Project Name group
7. In the Image Formats group, select
the image formats you whish to add in the cursor ( ) and
unselect the unwanted images. Just click on the image preview to select/unselect. To
know more about the desired Windows® image format, see What
is a Cursor topic.
9. When done,
click OK. The cursor is automatically
created with the various image formats you've selected:
Setting the hot spot
is a Cursor for more info).
3. Select Draw/Set Cursor Hot Spot or press K. Click to the location of the hot spot..
4. The new location flashes for a short moment. The new hot spot location is now defined.
CursorWorkshop has updated the hotspot for all the formats with the same size. In such case, we assume that the hot spot is located at the same coordinates. If this is not the case, you can select another format and change its location.
